MODIFIED ALCOHOL CLEANING SYSTEMS

Our cleaning systems are able to carry out the washing and drying treatment completely under vacuum. We use solvents of alcohol derivative (modified alcohols or better alchopropanol), which have a degreasing power, similar to chlorinated solvents, which are specifically used when the demand calls for a strong degreasing phase, certainly superior to hydrocarbons (similar in chemical-physical characteristics but different in their management). Basically they offer low toxicity and eco-toxicity, they evaporate completely without leaving residues on the pieces. They are non-corrosive and are able to remove water from metal surfaces, which is very important compared to chlorinated solvents, they do not require the use of stabilizers.

CUT

VOC Emissions, Pollution, Workforce exposure , Energy Costs , Water and Solvent Consumption, Carry-out Fluid , Waste Disposal

INCREASE

Operator Safety; Environmental Safety; Cleaning Efficiency on polar and non-polar soils.

The machines remove organic and non organic,
polar and non-polar contaminants and impurities such as: oil (whole and emulsions), lapping oils, polishing pastes, waxes, shavings, powders and particulates, greases, footprints, earth and foundry sands, salts, etc.

Total removal of all types of pollutants from treated (metallic and non-metallic) parts, simple or morphologically complex, with blind and threaded holes, tapped or rolled, planar or with recesses or cavities, up to the microstructure of the sintered material components

OUR STANDARD

The construction with high thickness AISI 304 stainless steel (DIN AISI 1.403) (not like the off-line of laundry machines) allows us to reach high vacuum rates to avoid stressing the solvent and also allows the pieces to dry very quickly.

The whole plant cycle; spray stage, immersion with or without ultrasound, solvent vapors and drying, takes place under vacuum, this guarantees the hermetic seal of the plant. Each washing stage is carried out with a clean solvent, in fact, each system is equipped with a double distiller that guarantees solvent is always ready and clean, even for short cycle times.

This turns into a continuous washing process and a high consistent washing quality.

Vacuum drying prevents airborne particles from contaminating the cleaned parts inside the process chamber in a hermetically sealed environment, therefore extremely clean, since the chamber is also “washed” with each work cycle.

The operator will not come into contact with the solvent even during maintenance. All the operations of loading and unloading of the solvent, of drainage take place automatically and the cleaning of the filters takes place with the preventive deodorization.

Our construction method is different from our competition in the market because the construction of our work chamber is integrated in the system body (we do not have many tanks and pipes that dissipate heat and in the long run do not guarantee sealing under vacuum conditions). Through our integrated module construction, we use the solvent vapors generated by the distiller to equip the chamber with thermal energy, so we have a continuous distillation and never interrupted, thus reducing the thermal energy used to restore the necessary distillation regime, reducing consumption electrical and always obtaining a greater quantity of vapors for the final phase of the process and for their condensation.

The relocation at the customer’s plant after the pre-acceptance tests in our factory, ensure that what is found in pre-testing is actually what is expected and required in the final testing phase and put into production. The system is independent and extremely flexible, since the installation is of the “plug-in” type, b eing equipped with independent heating and cooling systems therefore does not require further connections for heat sources or cooling water.

WHAT WE REMOVE

Total removal of all types of pollutants from treated (metallic and non-metallic) parts, simple or morphologically complex, equipped with blind and threaded holes, tapped or rolled, planar or with recesses or cavities, up to the microstructure of the sintered material components. We remove organic and non organic, polar and non-polar contaminants and impurities such as: oil (whole and emulsions), lappi ng oils, polishing pastes, waxes, shavings, powders and particulates, greases, footprints, earth and foundry sands, salts, etc…

WHICH MATERIAL CAN BE PROCESSED

Depending on the type of modified alcohol employed and the proposed cycle, our systems can optimally clean: AVP, AVZ, Steel, Stainless Steel, Cast Iron, Aluminum, Brass, Copper, Ergal, Plastic materials.

WHICH MATERIAL CAN BE PROCESSED

The baskets, once introduced into the treatment chamber, either manually via the operator or in automatic mode via a device positioned in front of the machine, can be moved or be static based on the type of program selected. It also takes into consideration the conformation or the delicacy of the pieces themselves:

The basket or baskets can be:

In rotation mode
Tilting mode – selected inclination
Static, no movement.

OUR STANDARD SUPPLY

• Completely stainless steel construction
• Flanged connections (not threaten)
• Vacuum operation of each part of the system
• Double continuous distillation
• Sludge stripping distiller (3rd)
• Ultrasounds with sweep mode
• Double washing liquid storage tank
• Integrated spray pumps
• Double Vacuum pumps
• Total full filtration at each cycle

• Chip drying and deodorizing before opening/ cleaning by the operator
• Hermetic washing / liquid loading / unloading system
• Continuous water separation
• Oil separation from the solvent
• Cryogenic abatement system
• Vacuum drying
• Siemens PLC operating
• Siemens HMI on-process system status
• Remote connection for hot-line assistance
• Complete integration within Industry 4.0
